Basic Information
Model NO.: ZK-1325
Cooling System: Water Cooling
Applicable Material: Nonmetal
Laser Classification: CO2 Laser
Color: Blue and White
Applicable Industry: acrylic, MDF, plastic, cloth, etc cutting job
Transport Package: packaged by plywood
Origin: China
Application: Textile Machinery, Automotive Industry, Shoemaking Industry, Advertising Industry, Jeans Cloth
Technical Class: Continuous Wave Laser
Structure Type: Gantry Type
Laser Technology: Laser Control RUIDA control system
Key Word: CO2 Laser cutting machine

_20220816163813

_20220816163818

Product Features
CO2 Laser cutting/engraving machines series are very popular in the market around the world. They have high stability and accuracy. Quality and price ratio is high.They employ stepper motor and driving system, LCD, PCB lamp motherboard, USB port
Water-cooling system

Optical design
Adopting the imported lens and mirros to ensure long lifetime of laser tube and high cutting efficiency

Mechanical design
1. The patented body adopts the most solid design which can ensure no deformation long time operation and transportation.
2. Adopts imported stepping motor and driver with its unique high speed outer guide rail.

Software design
1. Adopts International advanced RUIDA control technology, ensure high cutting engraving speed, high accuracy and high stability.
2. The machine system can be commanded by U disk without PC connection.
3. Can be directly support Autocad, Coreldraw software or their

Applications
Engraving and Cutting of paper, fabric, plastic, nonwoven cloth in garment and toy industries, also inclusive of precise cutting to non-metal materials, like acrylic and MDF board in handbag, glove, mold, advertisements, decoration, electrical appliance and plastic industries.

Materials
Wood work, paper, leather, cloth, organic glass, resin, acrylic, woolens, plastic, rubber, ceramic, crystal, jade, bamboo and other non-metal materials.

Samples

Parameter Model ZK 6040 ZK 9060 ZK 1080 ZK 1290 ZK1490 GLC-1610
Working area 600*400 900*600 1000*800 1200*900 1400*900 1600*1000
Laser power 70W/80W/100W/130W/150W
Laser type CO2 glass tube
Control system RUIDA control system
Drive mode Stepping Motor Microstep drive
Cooling mode Water-cooling and protection system
Working speed 0-1000(mm/s)
Graphics mode Plt, Dxf, Bmp, Pcx, Dst, etc
Platform types Honeycomb table, blade strip table (Optional)
Repeatability precision ≤0.02mm
Working voltage AC 220±10%/50-60Hz
Overall power consumption ≤1250w
N.W. 200KG 220KG 340KG 400KG 500KG 530KG
G.W. 290KG 320KG 440KG 520KG 600KG 660KG
Package Dimension(mm) 1630*960*1270 1850*1250*1270 1700*1500*1270 1900*1600*1270 2100*1600*1270 2240*1660*1270
Body configurations Software design 2. The machine system can be commanded by U disk without PC connection.
3. Can be directly support Autocad, Coreldraw software or their output, the documents like PLT, PCX, DXF, BMP etc.,
Working Environment Operating Humidity 5%-95%
Operating Temperature 0oC-45oC

Our Factory
_20200918125047

After-sale Sevice

<<< We offer professional after-sales installation and guidance, after-sales online. we can be remotely controlled by teamviwer, to help customers solve the problem.

<<< For on-line not solve the problem, we will arrange technical personnel to the customer's company offer after-sales service

<<
